REST architecture

REST (REpresentational State Transfer) is an architectural style Defined by HTTP 1.0 & 1.1 author (Roy Fielding).
It is not a protocol, nor a standard, but a set of constraints aiming at designing APIs that are centered around the notion of resources.
It leverages the HTTP protocol to provide a uniform interface to access resources.
A common standard in the industry is to design RESTful, Business oriented & Open Ready APIs

REST architecture: Pros & Cons

• Simple: Leverages HTTP Protocol
  • Well known, widely deployed
  • Use HTTP verbs
  • Use URI as a global identifier for resources
• Readable: Uniform Interface
  • Consistant interface accross all APIs.
  • Easy to read and understand by a human
• Portable & Flexible : Adapts very well to different platform and use cases
• Scalable: Statelessness -> Easy horizontal scaling
• Independence: Separation between client and server, allow for autonomous development accross sections of a project.

REST architecture: Set of constraints

When given a name, a coordinated set of architectural constraints becomes an architectural style

• Client-Server
• Uniform Interface
• Stateless
• Cacheable
• Layered System
• Code on Demand

REST constraints: Client-Server (1/6)

• A Client is someone who is requesting resources and are not concerned with data storage, which remains internal to each server
• Server is someone who holds the resources and are not concerned with the user interface or user state
• Allow components to evolve independently.

REST constraints: Uniform Interface (2/6)

• Identification of resources: each resource is uniquely identified in requests
• Manipulation of resources through representations: each resource has one or more representations
• Self-descriptive message: message is not only data but everything necessary for the message to be processed
• Hypermedia as the engine for application state (HATEOAS): the server must give the client the needed information to navigate the service

REST constraints: Stateless (3/6)

• The server will not store anything about the latest HTTP request the client made
• Request contains all necessary information
• No session
• No history
• The client is responsible for managing the state of the application.

REST constraints: Cacheable (4/6)

• Responses include whether the response is cacheable or not
• If cached, Client will return data from cache without the need to send the request again to the server
• Improves performance
• Risks of stale data

REST constraints: Layered System (5/6)

• Client has no idea about the end server or intermediates processing the requests, only the immediate layer with wich it interacts with
• Intermediary servers may improve system availability by enabling load-balancing and by providing shared caches
• The disadvantage is that they add overhead to the processing of data, which could reduce performance

REST constraints: Code on Demand (Optional) (6/6)

• Client are extendable by downloading executable code

Rules of RESTful API

REST Rules (1/7)

Identification of resources

• Should prefer naming resource with noun instead of verbs (!= RPC)
• Plural: /dogs
• Use Javascript naming convention
• Prefer hyphens (-) to underscores(_) for readability
• User lowercase

DO

/medical-units

DON'T

/MedicalUnit

REST Rules (2/7)

CRUD / HTTP Verbs

Implements CRUD using HTTP Methods

• POST = Create
• GET = Read
• PUT = Update
• DELETE = Delete

Status code

Should rely on standard HTTP status codes. For example:

• The requested medical unit does not exist: 404 Not Found
• The request is incoherent: 400 Bad Request
• An unexpected exception was raised: 500 Internal Server Error

REST Rules (3/7)

Collections

• 2 base URLs per resource
  • Collection
  • Element

GET /medical-units        # List all medical units
GET /medical-units/{id}   # Get a specific medical unit by ID

REST Rules (4/7)

Hierarchical structure

Use / to indicate hierarchical relationships

GET /hospitals
GET /hospitals/{id}
GET /hospitals/{id}/medical-units
GET /hospitals/{id}/medical-units/{id}

REST Rules (5/7)

Query strings

Allows to filter, sort, paginate, get partial responses, …

GET /hospitals/{id}/medical-units?type=cardiology                 # Filter
GET /hospitals/{id}/medical-units?page=2&per_page=50              # Pagination
GET /hospitals/{id}/medical-units?fields=name,location,capacity   # Partial responses

Custom verbs

GET /hospitals/{id}/medical-units/search?query=toto
GET /hospitals/count

REST Rules (6/7)

Internationalization (I18N)

• Use ISO 8601 standard for Date/Time/Timestamp
  • 2022-11-28 15:00:00.000
  • 2022-11-28
• Add support for different languages
  • Accept-Language: fr-CA, fr-FR
  • Not ?language=fr

REST Rules (7/7)

Content Negotiation

• Client asks for resources format type, in Accept header in order of preference
  • Accept: application/json, text/plain
  • Default is JSON

HATEOAS (Not mandatory, Nice to have)

• Use RFC5988 link notation to implement HATEOAS

{
    "dog": {
        "id": 243
        "name": "Wan",
        "race": "Golden Retriever",
        "owner": "John",
        "age": 5
    },
    "_links": [
        {
            "href": "https://example.org/api/v1/owners/135",
            "rel": "owner",
        }
    ]
}

Versioning

• Implementation can change, but not the interface. It is a contract between the client and the server.
• If the contract must be broken(introducing a breaking change), you should create a new API while temporarily keeping the old one, for retro-compatibility

PATCH /api/v1/hospitals/{id} '{"name": "HPP"}'
PATCH /api/v2/hospitals/{id} '{"label": "HPP"}'

JavaScript Object Notation (JSON)

• Lightweight standard for data-interchange format
• Developer-friendly
  • Easy for humans to read/write
  • Efficient to parse/generate
• Open, not only Javascript

JSON Types

• Number: 12 2.45
• String: "hello" 'hello'
• Boolean: true false
• Empty value: null
• Array: ordered values: [1, "apple", true, {...}]
• Object: unordered key/value pairs: {"title": Game of Thrones", "season": 1}

API First

• Start by defining the contract (define the API) before starting any development
• Use standard and normalized format (OpenAPI)
• Allow development teams to work in parallel
• Allow to discuss and validate the contract with the consumer before starting the development

Practical Work

Design an API using Apicurio

• Go to https://studio.apicur.io
• Create an account
• Create a new API and use the Pet Store Example Template
• Explore the "Preview Documentation"
• Explore the "Edit API", note how the example is designed and the raw definition (Source)

Assignment

• Using the pet store example as a base, we will design a new API.
• Create a new API Patient
• The patient resource should have the following attributes:
  • ID
  • Name
  • Birthdate
  • Sex
  • Social security number
• Design RESTful API endpoints giving the following capabilities:
  • List patients
  • Retrieve a specific patient information
  • Add a new patient
  • Delete a patient
  • Update a patient
  • Search patient by Social security number
    NB: The Patient resource is given as an example, if you want to design another resource, for your project for example, feel free to do so.

Push your work to Gitlab

• Push your OpenAPI specification to the Gitlab repository we created in the HTTP assignment.
• You can either
  • Export the spec, commit and push it to your Gitlab repository
  • Link your Apicurio account to your Gitlab's and use Apicurio "publish" feature to directly commit it in your Gitlab Repository
